| Flute shape optimizes chip form to improve chip flow and evacuation|Can be reconditioned up to 3 times to its original specification|Broad standard assortment|Customized solutions, supported by tailor made|Single diameter and drill chamfering tools as standard |
| 0 deg body half taper |
| Axial concentric coolant entry on circle |
| 20 bar coolant |
| Axial concentric coolant exit on circle |
| EFW feed direction |
| 16.3 deg orthogonal rake |
| 24.121 deg helix flute |
| 55 mm L body |
| 90 mm L functional |
| 36 mm L clamping |
| 32 mm L usable |
| 3 maximum regrinds |
| 1 mm L point |
| 3 mm L regrind |
| 12835 r/min |
| H6 connection diameter tolerance |
| H8 achievable hole tolerance |
| P material grade |
| 860.1..A1 (5xD) tool style |
