- Features
| 18 mm D maximum cutting |
| 20 life cycle state |
| 90 deg body workpiece side |
| Axial concentric coolant entry |
| 10 bar coolant |
| 48 - 60 mm OD minimum axial groove |
| Radial coolant exit |
| 40 mm Dia minimum inside axial groove |
| 90 deg cutting edge |
| 0 deg rake orthogonal |
| 18 mm L functional |
| 45.1 mm W functional |
| 0.1 mm H functional |
| 16 mm length to cutting item reference point |
| H insert seat size |
| 3 Nm torque |
| 0 deg inclination |
| 18 mm maximum overhang |
| 570-xxR/L123..B..A tool style |
| C-80 deg diamond insert shape |
