- Applications
- Features
| General Purpose |
| Fast-Acting |
| Used as supplementary protection in appliance or utilization equipment to provide individual protection for components or internal circuits |
| 0.0583 ohms resistance |
| 79.705 I2T (A2 sec) nominal melting |
| -55 to 125 deg C operating temperature |
| 4 hrs minimum at 100%, 1 hr maximum at 135%, 2 min maximum at 200% |
| Nickel-plated brass cap, tin plated copper leads |
| 100 A at 250 VAC interrupting rating |
| 10 kA at 125 VAC interrupting rating |
