Siemens 6EP13373BA00 SITOP Power Supply, 120 to 230 VAC Input, 24 VDC Output, 960 W, 40 A, DIN Rail Mount

Power Supplies
301310 MFG #: 6EP13373BA00
Siemens
1040.00000 / ea
10991_ID-PIC-v1-P_KT01_XX_01193E
  • Alternate Catalog Number: 6EP1337-3BA00
  • ARRA Compliant: C
  • Buy American Compliant: C
  • Catalog Number: 6EP13373BA00
  • Country of Origin: RO
  • Currency: USD
  • Depth: 125 mm
  • EU RoHS Indicator: C
  • Frequency Rating: 47 to 63 HZ
  • Gross Volume Per Pack: 358.86
  • Gross Volume UOM: in
  • Gross Weight Per Pack: 6.3930 lb
  • Gross Weight per Pack Metric: 2.90
  • Gross Weight UOM Metric: kg
  • Harmonization Tariff Schedule Code: 8504409520
  • Height: 5.5100 in
  • Height [Metric]: 13.9954 cm
  • Length: 11.0200 in
  • Length [Metric]: 27.9908 cm
  • Returnable: Y
  • Series: SITOP
  • Standards: ARRA CompliantBuy American Act CompliantRoHS CompliantCSA C22.2UL 508
  • Type: Stabilized
  • UNSPSC: 39121026
  • UPC 11: 66264329905
  • UPC 12: 662643299052
  • Width: 5.9100 in
  • Width [Metric]: 15.0114 cm
  • Stock Status: NORMALLY STOCKED
  • Brand: Siemens
  • Manufacturer: Siemens
  • Amperage Rating: 40 A
  • Input Voltage: 120/230 VAC
  • Mounting Type: DIN Rail
  • Output Voltage: 24 VDC
  • Power Rating: 960 W
QTY
Add to Wishlist
  • Features
Single phase
0 to 70 deg C operating
-40 to 85 deg C storage/transport
Green LED's for status display
Screw type terminal connection
IP20 degree of protection
Two parallel operation
15 A at 120 VAC, 8 A at 230 VAC input, 40 A output
