nVent HOFFMAN CONCEPT™ CSD303012SS CWS 1-Door Enclosure, 30 in L x 30 in W x 12 in D, NEMA 4X NEMA Rating, 304 Stainless Steel
Hoffman On-Demand
679229
MFG #: CSD303012SS
nVent HOFFMAN
3602.07000
/ ea
nVent HOFFMAN CONCEPT™ Enclosure, 1-Door, Series: CWS, 30 in Length, 30 in Width, 12 in Depth, NEMA 4X, Hinged Cover, 28.2 x 28.2 in Panel, Lock: Quarter Turn Latch, Wall Mount, 304 Stainless Steel, Brushed
- http://www.hoffmanonline.com(Seller Home Page URL)
- Install Instructions 1 URL - 11015_UR2KL0GPSQFCZMH9.pdf(Install Instructions 1 URL)
- Install Instructions 1 URL - stream_document.aspx?rRID=19409&pRID=350125(Install Instructions 1 URL)
- Install Instructions URL - stream_document.aspx?rRID=19409&pRID=350125(Install Instructions URL)
- Spec Sheet URL - Spec-00002.pdf(Spec Sheet URL)
- Tech Drawing URL - C2502-C.gif(Tech Drawing URL)
- Warranty URL - terms-of-sale(Warranty URL)
- Applications
- Features
| Controls and Drives; Corrosive Environments |
| Manufactured from Type 304 or Type 316L stainless steel, Minimum-width body flange provides maximum body opening, External formed 90-degree body flange, Panel mounting studs fit optional CONCEPT panels and other accessories, Mounting holes in back of body for direct mounting or for optional external mounting brackets, Type 316 stainless steel hidden hinges promote clean aesthetic appearance, Corner formed doors are interchangeable and easily removed by pulling clip-style hinge pins, Provision on door (except window-door style and when B = 12 in.) for thermoplastic data pocket, Provision on door (except window-door style and when B = 12 in.) for optional doorstop kit, Quarter-turn latches furnished with flush slotted insert, Seamless foam-in-place gasket, Self-grounding latch system with double seal, Bonding provision on door; grounding stud on body, Furnished har |
| Minimum width body flange provides maximum body opening |
| External formed 90 deg body flange channels away liquids |
| CONCEPT™ enclosures feature streamlined styling with an attractive stroked finish and flush quarter-turn latches for secure closure |
| Mounting brackets required to meet UL/CSA external mounting requirement |
| Corner formed doors are interchangeable and easily removed by pulling clip style hinge pins |
| quarter-turn latches furnished with flush slotted insert |
| Self-grounding latch system with double seal |
| Bonding provision on door, grounding stud on body |
| Furnished hardware kit consists of panel mounting fasteners, grounding hardware and sealing washers for wall mounting holes |
| Installation instructions provided |
| 16 ga 316L stainless steel |
| Installation instructions provided |
| 16 ga 316L stainless steel |
| Installation instructions provided |
| 16 ga 304 stainless steel |
| NO 4 smooth brushed finish |
