- Features
| 4 conductors |
| M30x1.5 mounting thread |
| 7/8-16 UN connection |
| -40 to 80 deg C operating temperature |
| TPU contact carrier material |
| Gold plated brass contact material |
| Nickel-plated housing |
| 5 pin, bare/red/black/white/blue pin color |
| 4 x 22 AWG, 22 AWG drain conductor |
| TPU, blue/gray molded material |
| 0.05 to 0.25 in max panel thickness |
| Gray PVC outer jacket material |
| PE/PVC conductor insulation material |
| Foil, thinned copper braid shielded |
