Square D™ I-Line™ PowerPact™ HJA261252 Type HJA Molded Case Circuit Breaker, 600 VAC/250 VDC, 125 A, 2 Poles
Molded Case Circuit Breakers
PDW~6403610
MFG #: HJA261252
Square D™
7006.50000
/ ea
The PowerPact™ H, J and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic™ electronic trip units. L-frame circuit breakers are available with Micrologic™ electronic trip units only. H and J-frame circuit breakers with thermal-magnetic trip units contain individual thermal (overload) and instantaneous (short circuit) sensing elements in each pole. The amperage ratings of the thermal trip elements are calibrated at 104 deg F free air ambient temperature. Per the National Electric Code® (NEC®) and the Canadian Electrical Code®, standard circuit breakers may only be applied continuously at up to 80% of their rating. Circuit breakers rated for 100% operation are available but require specially-designed enclosures and 194 deg F rated wire.
- Brochure URL - 11003_35R1PTDFMVK20N68.pdf(Brochure URL)
- Catalog URL - IDW_DOCUMENT_86e26fd7091d91eac4712e605cbef2835e4eb44b75b1f59c013fd6082b480e4e.pdf(Catalog URL)
- Computer~Aided [CAD|BIM] Model URL(Computer~Aided [CAD|BIM] Model URL)
- Computer~Aided [CAD|BIM] Model URL - files?p_enDocType=CAD&p_File_Name=HJA261252_2D+Bottom+View.dwg(Computer~Aided [CAD|BIM] Model URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Service Manual URL - 11003_T6POCH3LUD9I1KN0.pdf(Service Manual URL)
- Spec Sheet URL - 11003_JUAD97N3PL8O02HG.pdf(Spec Sheet URL)
- Tech Bulletin URL - 11003_9UXPLAQ71E6F2BGM.pdf(Tech Bulletin URL)
- Tech Bulletin URL - 11003_VRP57W264AQSK31L.pdf(Tech Bulletin URL)
- Tech Drawing URL - 11003_NXHQCU3FRB1G8O4K.pdf(Tech Drawing URL)
- Tech Drawing URL - 11003_O4QH52BCYUSITVJW.pdf(Tech Drawing URL)
- User Manual URL - 11003_E9IAMWVOKTCDJUNZ.pdf(User Manual URL)
- Video - https://www.youtube.com/embed/4wUOBk4oUmk(Video)
- Video - https://www.youtube.com/embed/eoDTK_hod_s(Video)
- Applications
- Features
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| I-LINE |
| Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
| 65 kA at 480 VAC, 25 kA at 600 VAC, 100 kA at 240 VAC, 20 kA at 250 VDC interrupt rating |
