Square D™ Homeline™ QO® Standard Miniature Circuit Breaker, 120/240 VAC, 20 A, 22 kA Interrupt, 1 Pole
Circuit Breakers
33137
MFG #: QOB120VH
Square D™
76.32000
/ ea
- 360 Degree View URL - 360(360 Degree View URL)
- 360 Degree View URL - index.html?pid=11003&id=8013240360Den&ext=webp(360 Degree View URL)
- 3D Rendering URL - SEproductListV2.html?p=QOB120VH(3D Rendering URL)
- Brochure URL - 11003_SF18VI3Y75ANRTGZ.pdf(Brochure URL)
- Brochure URL - files?p_enDocType=Brochure&p_File_Name=0102BR0201.pdf(Brochure URL)
- Catalog URL - Square_D_QOB115_Catalog.pdf(Catalog URL)
- Compliance Cert URL - Square_D_QOB120VH_Compliance_Certificate.pdf(Compliance Cert URL)
- Install Instructions 1 URL - 11003_YZ960BGHSVDUC4AN.pdf(Install Instructions 1 URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Spec Sheet URL(Spec Sheet URL)
- Spec Sheet URL - 11003_DGKP76NHFSMUB9RZ.pdf(Spec Sheet URL)
- User Manual URL - 11003_4OPHZUT6J8L1YG7E.pdf(User Manual URL)
- Tech Drawing URL - 11003_93TUED6K84M2FQY5.pdf(Tech Drawing URL)
- User Manual URL(User Manual URL)
- Tech Drawing URL - 11003_UGJBXD0A3H7IRO9L.pdf(Tech Drawing URL)
- Video - https://www.youtube.com/embed/h3tJoPmFAOw(Video)
- Applications
- Features
| HACR rated |
| STANDARD BOLT-ON |
| QO and QOB circuit breakers have an overcenter, trip-free toggle mechanism with quick-make, quickbreak action and positive handle indication |
| The tripping mechanisms in two-and three-pole circuit breakers operate such that an overcurrent on any pole of the circuit breaker will cause all poles of the circuit breaker to open simultaneously |
| Bolt-on QOB circuit breakers are for use in NQO and NQOD panelboards |
| QO and QOB circuit breakers have VISI-TRIP feature, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit |
| 14 - 10 AWG copper, 14 - 8 AWG copper/aluminum |
| Standard |
