SolaHD ES5H50S Ventilated Distribution Transformer, 240/480 VAC Primary, 120/240 VAC Secondary, 50 kVA, 60 Hz, 1 Phase
Isolation Transformers
346943
MFG #: ES5H50S
SolaHD™
2622.52000
/ ea
SolaHD Distribution Transformer, Ventilated, 240/480 VAC Primary, 120/240 VAC Secondary, 50 kVA, 60 Hz, 1 Phase, 208/104/416/208 A Maximum, (2) 2-1/2% FCAN/(4) 2-1/2% FCBN Taps, Wall Mount, 220 deg C, NEMA 3R, 150 deg C, Stainless Steel Housing, 18 in L x 18 in W x 31 in H
- Safety Data Sheet URL - General-Purpose-Ventilated-Xformer_.pdf(Safety Data Sheet URL)
- Seller Home Page URL - solahd(Seller Home Page URL)
- Seller Home Page URL - solahd.aspx(Seller Home Page URL)
- Spec Sheet 1 URL - SolaHD_E2H45S_Datasheet.pdf(Spec Sheet 1 URL)
- Spec Sheet URL - 11375_46126.pdf(Spec Sheet URL)
- Spec Sheet URL - 46126.pdf(Spec Sheet URL)
- Warranty URL - appleton-grp-terms-and-conditions.pdf(Warranty URL)
- Applications
- Features
| Any situation where the available voltage must be changed to accommodate the voltage required by the specific electrical circuit or connected equipment. |
| UL-3R ventilated outdoor enclosures when used with optional weather shields (order separately), UL class 220 DEG C/428 DEG F insulation system, 150 DEG C/302 DEG F temperature rise under full load, Terminal board connections and spacious wiring compartment, Panel enclosure design with wiring diagram on inside front cover reduces labor time, High efficiency for low cost operation, Compliant with NEMA TP-1 standards, Single and three phase models. |
| Terminal board connections and spacious wiring compartment |
| Panel enclosure design reduces labor time, wiring diagram on inside front cover |
| High efficiency for low cost operation |
| Copper wound designs |
| Low temperature designs |
| Electrostatic shield for quality power |
| Energy efficient dry-type, fast delivery, isolation type |
| NEMA 3R with optional weather shield (WS-17), ventilated |
| 208/104 A primary, 416/208 A secondary |
