SmartlockPro® AFTR2-T Duplex AFCI Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, Light Almond
AFCI Receptacles
730673
MFG #: AFTR2-T
Leviton®
33.79000
/ ea
- Application GDE URL - Leviton_TBR15_GY_Application_Guide.pdf(Application GDE URL)
- http://www.leviton.com(Seller Home Page URL)
- Owners Manual URL - SmartlockPro_AFTR2_Manual.pdf(Owners Manual URL)
- Safety Data Sheet URL - MSDS.pdf(Safety Data Sheet URL)
- Spec Sheet URL - 10962_ID-SPE-v1-G-8712D_AFCI_Devices_PB_final.pdf(Spec Sheet URL)
- Spec Sheet URL - ibcGetAttachment.jsp?cItemId=128827&label=IBE&appName=IBE(Spec Sheet URL)
- Video - https://youtube.com/embed/RCcF6HGPaFo(Video)
- Applications
- Features
| Residential, Commercial |
| Device Design Reduces Nuisance Tripping, Impact-Resistant Thermoplastic Cover and Body, Superior Resistance to Electrical Surges and Over-Voltages, Compatible with all Decora Devices and Wallplates, Packed with Coordinating Wallplate, with Led Indicator, Backed by Leviton's Limited Two-Year Product Warranty |
| Device design reduces nuisance tripping |
| Impact-resistant thermoplastic cover and body |
| Superior resistance to electrical surges and over voltages |
| Compatible with all Decora devices and wallplates |
| Packed with coordinating wallplate |
| Use of TEST and RESET buttons is similar to traditional GFCI receptacles of which consumers have become familiar with. This translates into greater acceptance of the technology and a more user-friendly platform |
| Automatically tests the AFCI every time the Reset button is depressed; the AFCI will not reset if the AFCI circuit is not functioning properly |
| By blocking reset of the AFCI if protection has been compromised, the SmartlockPro OBC AFCI reduces the possibility of end-users incorrectly assuming that a reset AFCI is providing protection when its functionality has been compromised |
| A line-load reversal diagnostic feature is provided which prevents the AFCI from being reset and stops power from being fed to the AFCI receptacle face or through to downstream devices, a green LED indicator on the AFCIs face also illuminates to alert the installer to a line-load wiring reversal when the device is in the tripped state |
| TR symbol indicates the devices compliance with the latest NEC® requirements for tamper-resistant receptacles in residences and childcare facilities |
| Galvanized steel strap |
| Flammability rated V-2 per UL94 |
| 1250VAC per UL 1699A dielectric voltage |
| Tamper-resistant |
| Monochromatic |
| Nylon wallplate/faceplate |
| Back and Side wired |
| 1 |
