Siemens SpeedFax™ Q220AFCH Arc-Fault Circuit Breaker, 120/240 VAC, 20 A, 22 kA Interrupt, 2 Poles, Thermal Magnetic Trip
Arc-Fault Circuit Breakers
807562
MFG #: Q220AFCH
Siemens
398.84000
/ ea
AFCI's detect arcing faults (an unintentional arcing condition in a circuit) that standard circuit breakers are unable to detect. The device is intended to mitigate the effects of arcing faults by functioning to de-energize the circuit when an arcfault is detected.
- Catalog 1 URL - Siemens_Q220AFC_Catalog.pdf(Catalog 1 URL)
- Catalog URL - Siemens_Q220AFC_Catalog.pdf(Catalog URL)
- http://www.sea.siemens.com(Seller Home Page URL)
- Spec Sheet URL - SIEMEAE21805_1_26.pdf(Spec Sheet URL)
- Spec Sheet URL - 10991_TGBMSPY58C2NOWIK.pdf(Spec Sheet URL)
- Spec Sheet URL - DatasheetService?format=PDF&caller=EGH&mlfbs=US2:Q220AFCH&language=en(Spec Sheet URL)
- User Manual URL - man(User Manual URL)
- User Manual URL - SIE_IS_AFCI_2P.pdf(User Manual URL)
- Applications
- Features
| PARALLELANDSERIESARCINGPROTECTION |
| 22kAINTERRUPT |
| Long time and instantaneous |
| Detects all three possible types of arc faults - line to ground, line to neutral and series |
| 14 to 8 AWG copper, 12 to 8 AWG aluminum |
