- Applications
- Features
| For 28.0 - 32.2 AMP Full Load Motor |
| Enclosure: NEMA 1P |
| Ambient compensated heater |
| Ensure reliable protection for equipment |
| 28.0 - 32.2 A for size 1P, 34.9 - 36.9 A for size 2, 2.5 class 14, 22 (1 phase), 29.6 - 32.5 A for 48DA, 48GA, 30.1 - 33.2 A for 48HA class 48 (1 phase) |
| 24.5 - 25.9 A for size 00, 0, 1, 25.4 - 26.9 A for size 1.75, 25.4 - 26.9 A for size 2, 2.5, 30.0 - 33.5 A for size 3, 3.5 class 14, 17, 18, 22, 25, 26, 30, 32, 83, 84, 87 (3 phase), 27.3 - 29.2 A for 48DC, 27.3 - 29.2 A for 48GC, 30.1 - 33.2 A for 48HA class 48 (3 phase) |
