Schneider Electric RM17UAS15 RM17-U 1-Phase Self-Powered Overvoltage/Undervoltage Voltage Control Relay, 5 A, 1CO Contact, 110 to 240 VAC/VDC V Coil
Control Relays
1207264
MFG #: RM17UAS15
Square D™
138.00000
/ ea
Schneider Electric Voltage Control Relay, 1-Phase Self-Powered Overvoltage/Undervoltage, Series: RM17-U, 5 A, 3 VA, 50/60 Hz, 110 to 240 VAC/VDC Coil, 1CO, 5 A at 12/13/14/15 VAC, 12/13/14 VDC Contact, DIN Rail Mount, Threaded Terminal, LED, IP20/IP30, -20 to 50 deg C, 0.69 in W
- 360 Degree View URL - index.html?pid=11003&id=10866033360Den&ext=webp(360 Degree View URL)
- Brochure URL - 17bb139b4370aa8ad3b5cf465e6a7fb767e8275c.pdf(Brochure URL)
- Computer~Aided [CAD|BIM] Model URL(Computer~Aided [CAD|BIM] Model URL)
- Install Instructions 1 URL - 11003_QECMSDHN62LOJ83W.pdf(Install Instructions 1 URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Service Manual URL - 11003_VB13ZTYFUI5O04H9.pdf(Service Manual URL)
- Spec Sheet URL - 11003_M3XA8O9E0ZJITUQR.pdf(Spec Sheet URL)
- Applications
- Features
| DC Voltage Control Applications |
| for power ON LED (green); for relay ON LED (yellow) |
| 250/400 VAC conforming to IEC 60664-1 rated insulation voltage |
| Self-extinguishing plastic housing |
| 360 operations/hr under full load operating rate |
| Insulation between supply and measurement |
| 10 mA at 5 VDC minimum switching current |
| 95% at 55 deg C conforming to IEC 60068-2-30 relative humidity |
| -4 to 122 deg F storage temperature |
| Self-powered, overvoltage or under voltage |
| IP20 (terminals) conforming to IEC 60529-IP30 (casing) conforming to IEC 60529 |
