Schneider Electric Multi 9™ 60104 Miniature Circuit Breaker, 120 VAC/60 VDC, 3 A, 10 kA Interrupt, 1 Pole, Thermal Magnetic Trip
Circuit Breakers
62145
MFG #: 60104
Square D™
108.63000
/ ea
Schneider Electric 60104 MINIATURE CIRCUIT BREAKER 120V 3A,35mm DIN rail,3A,50/60 Hz,60 V DC-125 V DC-120...240 V AC 50/60 Hz,60 V DC-125 V DC-120...240 V AC 50/60 Hz,7 to 10 times ampere rating,73 mm,Box Lug Box Lug,C,C60,C60 UL489,miniature circuit-breaker,C60,Multi 9,IP40 (Case) - IP20 (Terminals),UL 489 - CSA C22.2 No.5
- 360 Degree View URL(360 Degree View URL)
- 360 Degree View URL - 360(360 Degree View URL)
- Brochure URL - 11003_XJ3GT4OHS5MRQ208.pdf(Brochure URL)
- Brochure URL - 5430777ee56dfe2ed5d0f860e8d076d8ddee6ea1.pdf(Brochure URL)
- Catalog URL - IDW_DOCUMENT_3055cef7572f2db8c82c538c2984d4b8dd759efbe581e5c69cf67b443886c5b0.pdf(Catalog URL)
- Compliance Cert URL - Schneider_Electric_60104_Compliance_Certificate.pdf(Compliance Cert URL)
- Computer~Aided [CAD|BIM] Model URL - 659e98d4f512b79d8e68427f177a53fd1bb0b670(Computer~Aided [CAD|BIM] Model URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Spec Sheet URL - 11003_F2BPLIWKMU68O35Z.pdf(Spec Sheet URL)
- Spec Sheet URL - 6601b6a9fbe2e3bde6bcca9b99d28224125352a4.pdf(Spec Sheet URL)
- Tech Bulletin URL - 11003_84OUJZFW362M1KAG.pdf(Tech Bulletin URL)
- Tech Bulletin URL - eb20308c55d73b579c0f6338b719cdf008fd75c2.pdf(Tech Bulletin URL)
- Tech Drawing URL - 11003_UNDF7RIEYHM3OZ6T.dwg(Tech Drawing URL)
- Tech Drawing URL - 7054693fcb339661cb365c344316fc4fb25be8e6(Tech Drawing URL)
- Applications
- Features
| Distribution |
| ON/OFF indication |
| Fast closing allows increased withstand to the high inrush currents of some loads |
| Trip free mechanism contacts cannot be held in the I-ON position when the circuit breaker is tripped automatically |
| Positive indication of contact disconnect |
| Green mechanical indication on front face of circuit breaker shows that all poles are open |
| Allows locking in O-OFF position using padlock attachment |
