Square D™
Schneider Electric MG17443 Multi 9™ C60 Supplementary Protector, 240/415/440 VAC/125 VDC, 1.5 A, 5 kA at 480Y/277 VAC Interrupt
Custom_Product_Images_Illustration
Square D™
Schneider Electric MG17443 Multi 9™ C60 Supplementary Protector, 240/415/440 VAC/125 VDC, 1.5 A, 5 kA at 480Y/277 VAC Interrupt
SKU224349
MFGR #MG17443
Your Cost: $240.34/ea
Schneider Electric MG17443 SUPP PROTECTOR 480Y/277V 1.5A 2P,1.5 A,10 kA,125 V at DC-120/240 V at AC-480Y/277 V at AC,125 V at DC-120/240 V at AC-480Y/277 V at AC,2-Pole,C,DIN Rail (35mm),Multi 9,Multi 9,standard,UL 1077 Recognized, IEC 60947-2 Rated,miniature circuit-breaker
Schneider Electric MG17443 SUPP PROTECTOR 480Y/277V 1.5A 2P,1.5 A,10 kA,125 V at DC-120/240 V at AC-480Y/277 V at AC,125 V at DC-120/240 V at AC-480Y/277 V at AC,2-Pole,C,DIN Rail (35mm),Multi 9,Multi 9,standard,UL 1077 Recognized, IEC 60947-2 Rated,miniature circuit-breaker
Actuator TOGGLE mm Application Distribution ARRA Compliant N Buy American Compliant N Catalog Number MG17443 Color Gray Connection TUNNEL TYPE TERMINAL TOP OR BOTTOM) 2.5-25 MMA² AWG 14...AWG 4) - RIGID Country of Origin FR Dimensions 3.19 in H x 1.42 in W x 2.87 in D EU RoHS Indicator N Frequency Rating 50/60 Hz Gross Weight Per Pack 0.5300 lb Harmonization Tariff Schedule Code 8536200020 Height 81 MM Item Group 00908 Length 73 MM Mounting Type Clip-On/DIN Rail Number Of Poles 2 Operating Temperature -30 to 70 °C Returnable Y Standard GB 14048.2-EN/IEC 60947-2-UL 1077-CSA C22.2 NO 235,IP20IEC 60529-IP40 MODULAR ENCLOSURE)IEC 60529,UR-CSA-CCC-IEC Standards UL 1077File No. E90509GB 14048.2CCC/CE CertifiedCSA C22.2 No. 235179014EN/IEC 60947-2Green PremiumRoHS CompliantARRABuy American Act Compliant Sub Brand C60 UL1077,MULTI 9 C60 Temperature Rating -22 to 158 °F Type Miniature circuit-breaker UNSPSC 39121603 UPC 11 78590188947 UPC 12 785901889472 Width 36 mm Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 1.5 A Interrupt Rating 20 KA-10 KA-5 KA-10 KA-5 KA-10 KA-10 KA-6 KA-10 KA-20 KA-10 KA-6 KA-10 KA-10 KA Trip Type Thermal-magnetic Voltage Rating 240 V-415 V-440 V-125 V A DISTRIBUTION ON/OFF INDICATION Trip free mechanism contacts cannot be held in the on position when the C60 is tripped automatically Positive indication of contact disconnect Green mechanical indication on front face of device shows that all poles are open Overcurrent protection for all application types Magnetic release operates from 7 to 10 times ampere rating Allows locking in ON-OFF position using padlock attachment
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator | TOGGLE mm |
| Application | Distribution |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | MG17443 |
| Color | Gray |
| Connection | TUNNEL TYPE TERMINAL TOP OR BOTTOM) 2.5-25 MMA² AWG 14...AWG 4) - RIGID |
| Country of Origin | FR |
| Dimensions | 3.19 in H x 1.42 in W x 2.87 in D |
| EU RoHS Indicator | N |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.5300 lb |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 81 MM |
| Item Group | 00908 |
| Length | 73 MM |
| Mounting Type | Clip-On/DIN Rail |
| Number Of Poles | 2 |
| Operating Temperature | -30 to 70 °C |
| Returnable | Y |
| Standard | GB 14048.2-EN/IEC 60947-2-UL 1077-CSA C22.2 NO 235,IP20IEC 60529-IP40 MODULAR ENCLOSURE)IEC 60529,UR-CSA-CCC-IEC |
| Standards | UL 1077File No. E90509GB 14048.2CCC/CE CertifiedCSA C22.2 No. 235179014EN/IEC 60947-2Green PremiumRoHS CompliantARRABuy American Act Compliant |
| Sub Brand | C60 UL1077,MULTI 9 C60 |
| Temperature Rating | -22 to 158 °F |
| Type | Miniature circuit-breaker |
| UNSPSC | 39121603 |
| UPC 11 | 78590188947 |
| UPC 12 | 785901889472 |
| Width | 36 mm |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 1.5 A |
| Interrupt Rating | 20 KA-10 KA-5 KA-10 KA-5 KA-10 KA-10 KA-6 KA-10 KA-20 KA-10 KA-6 KA-10 KA-10 KA |
| Trip Type | Thermal-magnetic |
| Voltage Rating | 240 V-415 V-440 V-125 V A |
| DISTRIBUTION |
| ON/OFF INDICATION |
| Trip free mechanism contacts cannot be held in the on position when the C60 is tripped automatically |
| Positive indication of contact disconnect |
| Green mechanical indication on front face of device shows that all poles are open |
| Overcurrent protection for all application types |
| Magnetic release operates from 7 to 10 times ampere rating |
| Allows locking in ON-OFF position using padlock attachment |
