Schneider Electric MG17422 Multi 9™ C60 Supplementary Protector, 240/415 VAC/60 VDC, 1.2 A, 5 kA at 277 VAC Interrupt, 1 Pole
Custom_Product_Images_Illustration
Square D™
Schneider Electric MG17422 Multi 9™ C60 Supplementary Protector, 240/415 VAC/60 VDC, 1.2 A, 5 kA at 277 VAC Interrupt, 1 Pole
SKU774407
MFGR #MG17422
Your Cost: $111.35/ea
Schneider Electric MG17422 SUPPLEMENTARY PROTECTOR 277V 1.2A 1P,1-Pole,1.2 A,10 kA,120/240 V at AC-60 V at DC-480Y/277 V at AC,120/240 V at AC-60 V at DC-480Y/277 V at AC,D,DIN Rail (35mm),Multi 9,Multi 9,motor protection,UL 1077 Recognized, IEC 60947-2 Rated,miniature circuit-breaker
Schneider Electric MG17422 SUPPLEMENTARY PROTECTOR 277V 1.2A 1P,1-Pole,1.2 A,10 kA,120/240 V at AC-60 V at DC-480Y/277 V at AC,120/240 V at AC-60 V at DC-480Y/277 V at AC,D,DIN Rail (35mm),Multi 9,Multi 9,motor protection,UL 1077 Recognized, IEC 60947-2 Rated,miniature circuit-breaker
Actuator TOGGLE mm Application Distribution ARRA Compliant N Buy American Compliant N Catalog Number MG17422 Color Gray Connection TUNNEL TYPE TERMINAL TOP OR BOTTOM) 2.5-25 MMA² AWG 14...AWG 4) - RIGID Country of Origin FR Dimensions 3.19 in H x 0.71 in W x 2.87 in D EU RoHS Indicator N Frequency Rating 50/60 Hz Gross Weight Per Pack 0.2700 lb Harmonization Tariff Schedule Code 8536200020 Height 81 MM Item Group 00908 Length 73 MM Mounting Type Clip-On/DIN Rail Number Of Poles 1 Operating Temperature -30 to 70 °C Returnable Y Standard GB 14048.2-EN/IEC 60947-2-UL 1077-CSA C22.2 NO 235,IP20IEC 60529-IP40 MODULAR ENCLOSURE)IEC 60529,UR-CSA-CCC-IEC Standards UL 1077File No. E90509GB 14048.2CCCCSA C22.2 No. 235179014EN/IEC 60947-2ARRABuy American Act Compliant Sub Brand C60 UL1077,MULTI 9 C60 Temperature Rating -22 to 158 °F Type Miniature circuit-breaker UNSPSC 39121603 UPC 11 78590188472 UPC 12 785901884729 Width 0.7086 in Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 1.2 A Interrupt Rating 10 KA-10 KA-3 KA-3 KA-10 KA-10 KA-10 KA-5 KA-10 KA-10 KA-5 KA-10 KA Trip Type Thermal-magnetic Voltage Rating 240 V-60 V-415 V VAC DISTRIBUTION ON/OFF INDICATION Trip free mechanism contacts cannot be held in the on position when the C60 is tripped automatically Positive indication of contact disconnect Green mechanical indication on front face of device shows that all poles are open Overcurrent protection for loads with high inrush currents Magnetic release operates between 10 and 14 times ampere rating Allows locking in ON-OFF position using padlock attachment
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator | TOGGLE mm |
| Application | Distribution |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | MG17422 |
| Color | Gray |
| Connection | TUNNEL TYPE TERMINAL TOP OR BOTTOM) 2.5-25 MMA² AWG 14...AWG 4) - RIGID |
| Country of Origin | FR |
| Dimensions | 3.19 in H x 0.71 in W x 2.87 in D |
| EU RoHS Indicator | N |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.2700 lb |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 81 MM |
| Item Group | 00908 |
| Length | 73 MM |
| Mounting Type | Clip-On/DIN Rail |
| Number Of Poles | 1 |
| Operating Temperature | -30 to 70 °C |
| Returnable | Y |
| Standard | GB 14048.2-EN/IEC 60947-2-UL 1077-CSA C22.2 NO 235,IP20IEC 60529-IP40 MODULAR ENCLOSURE)IEC 60529,UR-CSA-CCC-IEC |
| Standards | UL 1077File No. E90509GB 14048.2CCCCSA C22.2 No. 235179014EN/IEC 60947-2ARRABuy American Act Compliant |
| Sub Brand | C60 UL1077,MULTI 9 C60 |
| Temperature Rating | -22 to 158 °F |
| Type | Miniature circuit-breaker |
| UNSPSC | 39121603 |
| UPC 11 | 78590188472 |
| UPC 12 | 785901884729 |
| Width | 0.7086 in |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 1.2 A |
| Interrupt Rating | 10 KA-10 KA-3 KA-3 KA-10 KA-10 KA-10 KA-5 KA-10 KA-10 KA-5 KA-10 KA |
| Trip Type | Thermal-magnetic |
| Voltage Rating | 240 V-60 V-415 V VAC |
| DISTRIBUTION |
| ON/OFF INDICATION |
| Trip free mechanism contacts cannot be held in the on position when the C60 is tripped automatically |
| Positive indication of contact disconnect |
| Green mechanical indication on front face of device shows that all poles are open |
| Overcurrent protection for loads with high inrush currents |
| Magnetic release operates between 10 and 14 times ampere rating |
| Allows locking in ON-OFF position using padlock attachment |
