| Optimized for machining of small high quality features |
| High precision and repeatability |
| Reliable and easy-to-use clamping system |
| Locking precision - solid carbide boring bar fits precisely into the adaptor with a locating pin, rigid clamping with increased stability with collet clamped adaptors |
| 2.7 mm Dia minimum bore |
| 0 deg orthogonal rake |
| 98 deg cutting edge |
| 0 deg inclination |
| 27.25 mm L functional |
| 10 mm L usable |
| 13 mm maximum overhang |
| -8 deg lead |
| 17 deg ramping |
| 2.05 mm W body |
| 1.2 mm W functional |
| 1 edge |
| Cylindrical mounting |
| Positive rake |
