SWITCH,SNAPCONN,3W,20A120/277V,WH,NA
Toggle Switches
782612
MFG #: SNAP1223WNA
Hubbell Wiring Device-Kellems
14.13000
/ ea
Wiring Device-Kellems SNAPConnect® Toggle Switch, 3-Way Heavy Duty, 120/277 VAC, 20 A, 1/2 hp, Toggle, Screw Terminal, 50000 Operating Cycles, Thermoplastic, White, Environmental Conditions: -40 to 75 deg C Temperature, 4.18 in H x 1.3 in W x 1.74 in D
- http://www.hubbell-wiring.com/(Seller Home Page URL)
- Install Instructions 1 URL - 11456_QCO2RDBPX04JTAMG.pdf(Install Instructions 1 URL)
- Install Instructions URL - IDW_DOCUMENT_1487177548556.pdf(Install Instructions URL)
- Line Drawing URL - 11456_YC0J5DXUQSRWAL7B.pdf(Line Drawing URL)
- Spec Sheet URL - 11456_7YIQ4VDGLUTB6K0A.pdf(Spec Sheet URL)
- Tech Drawing URL - WIRING_SNAP1223WNA_M11586_ACAD_DRAWING.dwg(Tech Drawing URL)
- Warranty URL - 11456_Y8PS6T0FNOGH3Q75.pdf(Warranty URL)
- Applications
- Features
| SNAPConnect Heavy Duty |
| SNAP Connect, Automatic self-grounding |
| Steel, zinc plated bridge is corrosion resistant |
| Thread cleaning captive mounting screw |
| Automatic self-grounding staple assures continuity to wall box |
| Abuse resistant nylon toggle for heavy use applications |
| Eliminates exposed live parts |
| Stainless steel autoground clip |
| 2 position |
| Indoor Dry unless protected by additional means |
| Specification grade |
| 1 hp at 120 VAC, 2 hp at 208/240/277 VAC |
| Nylon toggle |
| UL 94-V2 flammability |
| 5540 W power |
| Positive snap action |
