Ideal® 89-310 Double Row Terminal Strip, 150 VAC, Clear/White, 20 A, 22 to 14 AWG Size
Terminal Block Strips & Barrier Blocks
63905
MFG #: 89-310
IDEAL®
27.70000
/ ea
IDEAL® Terminal Strip, Double Row, 150 VAC, 20 A, 10 Terminals, 22 to 14 AWG Wire, 3/8 in Center Spacing, #6-32 Screw, 9 in-lb, Surface Mount, Philslot Screw, -40 to 260 deg F, Thermoplastic, Clear/White, 4.4 x 4.12 x 0.88 in
- Brochure URL - 11020_V0OAHZ1TUMGYXB4R.pdf(Brochure URL)
- Brochure URL - 89-300Series%20TerminalStrip-dimensions.pdf.pdf(Brochure URL)
- http://www.idealindustries.com(Seller Home Page URL)
- Material Composition - US_ROHS_COMPLIANCE_STATEMENT_REV_2_23_2015.PDF(Material Composition)
- ROHS Compliance URL(ROHS Compliance URL)
- Spec Sheet 1 URL - IDEAL_89_310_Datasheet_1.pdf(Spec Sheet 1 URL)
- Spec Sheet URL - prodDetail.do?prodId=89-310(Spec Sheet URL)
- Features
| Features: Torque Rating of 9 in-lbs; Rugged base eliminates breakage; Center spacing 0.375 IN (9.52 mm); Accepts #22 to #14 AWG wire; Corrosion resistant surface plates w/ #6-32 philslot screws; Rated to 150V, 20A; Accessory jumpers available; Heavy-duty, corrosion-resistant screws, surface plates and optional hardware; Accessory hardware provides a variety of termination options; Available cover helps prevent contact with live terminals; Rugged polyester thermoplastic base (UL Rated 94V-0); Operating temperature rated from 130°C (260°F) to -40°C (-40°F); UL Recognized (E62622) and CSA Certified (LR15364).; Number Of Circuits: 10; Torque Rating: 9 IN-LB; Terminal Screw Size: 10 |
| Heavy duty, corrosion-resistant screws, surface plates and optional hardware |
| Accessory hardware provides a variety of termination options |
| Rugged polyester thermoplastic base |
| Rugged base eliminates breakage |
