CCI® 972721606 CAT6 23/4P CMR 1M'RIB BLUE
Riser Rated Copper Category Cables
150741
MFG #: 97272-16-06
Coleman Cable
235.77000
/ ft
CCI® Riser Cable, Type CMR Cat 6 Twisted Pair, 4 Conductors, Solid Bare Copper Conductor, 23 AWG Conductor, 0.21 in Outside Dia, 1000 ft Rib Length, 9.38 Ohm, Polyethylene Insulation, PVC, Blue. Images shown for wire are for illustrative purposes only. Color shade and packaging/spooling may vary.
- Features
| 600 MHz operating frequency |
| 5.6 nF/100 m maximum capacitance |
| 45 ns/100 m maximum delay skew |
| Each pair has different lay length for cross-talk prevention and ripcord added |
| 71% nominal velocity of propagation |
| 54.5 dB/100 m maximum insertion loss |
| 32.6 dB minimum next loss |
| 14.7 dB minimum return loss |
| Utilizes a small round filler design providing a smaller diameter and greater flexibility for easier handling |
| Lead free jacket |
| Category 6 Cable |
| White/blue with blue, white/orange with orange, white/green with green, white/brown with brown paired cable color |
| 9.38 Ohm/100 m at 20 deg C max DC resistance |
| 100 +/-15 Ohm at 1 to 100 MHz characteristic impedance |
