Amprobe® VolTect™ AM-570 Digital Multimeter, 1000 VDC/VAC, 10A, 60 MOhm, 1000 VAC/VDC, 10 A, 60 MOhm
Multimeters
774678
MFG #: AM-570
Amprobe
287.99000
/ ea
Amprobe AM-570 is the best multimeter in its class designed for professional electricians who need to maintain service or troubleshoot advanced electrical systems in the most demanding environments. Packed full of features such as true-rms, dual thermocouples for taking differential temperature measurements, a low impedance function to detect stray voltage, and a low pass filter to accurately take measurements on variable frequency drives, the Amprobe AM-570 Digital Multimeter allows for quick go-no-go checks without the need for an additional tool.
- Catalog URL - IDW_DOCUMENT_33cb5810f963b4faff37936e75821e353fe6afd57f85f533d15a164a2709877f.pdf(Catalog URL)
- http://www.fluke.com(Seller Home Page URL)
- Video - http://content.amprobe.com/video-dmm/Amprobe-AM-570.html(Video)
- Owners Manual URL - 11095_XWBROJFE97Q28SD3.jpg(Owners Manual URL)
- Spec Sheet URL - 11095_Spec sheet reference.pdf(Spec Sheet URL)
- Applications
- Features
| electrical |
| Low Z - to detect stray voltages |
| True-RMS technology improves accuracy in electrically noisy environments |
| Measures AC/DC voltage up to 1000 VAC/VDC current, resistance, frequency, capacitance, duty cycle and temperature |
| Low Z mode detects stray voltages |
| Low pass filter accurately measures voltage on variable frequency drives |
| Peak hold (crest) captures and holds the peak value of a voltage or current surge |
| Non-contact voltage detection enhances safety |
| Audible continuity quickly identifies shorts and open circuits |
| Diode test to verify diode polarity |
| Data hold freezes the reading on the display for further analysis |
| Maximum/minimum recording measurements over time to show voltage fluctuations |
| Relative zero mode displays the difference between the actual reading and a stored reference value and may be used with any function or range |
| Warning alerts against improper test leads connection |
| Combines user friendly features such as, auto power off to conserve battery life, low battery warning, a third hand test probe holder, built-in test leads storage, a built-in flashlight and a Velcro strap to hang the meter |
| Auto and manual ranging delivers maximum flexibility |
| Dual reading backlit LCD display with analog bar graph makes it easy to view results |
| +/-1.2% RDG + 5 LSD AC current accuracy |
| +/-1% RDG + 2 LSD DC current accuracy |
| +/-0.1% RDG + 3 LSD frequency accuracy |
| +/-1% RDG + 2 LSD resistance accuracy |
| +/-3% RDG + 5 LSD capacitance accuracy |
