Acme Electric® TF220255S Export Model, Three Phase, 50-60 Hz, 440 Delta Primary Volts, 220Y-127 Secondary Volts
General Purpose - Multi-Use Transformers
PDW~1599368
MFG #: TF220255S
Acme Electric
7847.72000
/ ea
LOW VOLTAGE DISTRIBUTION TRANSFORMER 3 PHASE 25KVA 440-220Y127
- Catalog URL - Acme_Electric_T279745S_Catalog.pdf(Catalog URL)
- Install Instructions 1 URL - 11112_GMEQCKR8X4L35ATS.pdf(Install Instructions 1 URL)
- Install Instructions 1 URL - 11112_HP5W1VA2YL0ZOUM3.pdf(Install Instructions 1 URL)
- Safety Data Sheet URL - HCC_SDS.pdf(Safety Data Sheet URL)
- Seller Home Page URL - en(Seller Home Page URL)
- Spec Sheet URL - 11112_2ZJUF5I9PEL0ATVM.pdf(Spec Sheet URL)
- Tech Drawing URL - TF220255S.dwg(Tech Drawing URL)
- Warranty URL - WAR_product_warranty_information.pdf(Warranty URL)
- Applications
- Features
| Ventilated |
| With weather shield, UL type 3R enclosure or type 2 enclosure without weather shield |
| Extra large wiring compartment for easier installation and cooler case temperatures |
| NEMA standard bus bar terminals, no special tools needed to make clearly marked connections tap changing easily accomplished with jumpers |
| Aluminum windings for increased insulation life, cooler operation, lower losses |
| Noise and vibration isolating pads standard to assure quiet operation |
| Large permanently legible nameplates on front |
| Single phase units can be banked for 3-phase service |
| All units have ground studs for use with non-metallic conduit |
| Suitable for wall or trapeze mounting wall brackets are available for units up to 50 kVA single and 75 kVA 3-phase |
| Quiet operation with sound levels below NEMA standards |
| Electrostatic shield for enhanced protection |
