Fluke® SureGrip™ ToolPak™ FLUKE-179/EDA2 Digital Multimeter Combo Kit, 1000 VDC/VAC, 10 A, 50 MOhm, 9 Pieces
Multimeters
334100
MFG #: FLUKE-179/EDA2
Fluke®
499.99000
/ ea
- Alternate Catalog Number: 2718166
- Amperage Rating: 10 A
- ARRA Compliant: C
- Battery: Alkaline 200 HR Typical, Without Backlight
- Battery Type: Alkaline
- Buy American Compliant: C
- Capacitance: 10000 MFD
- Catalog Number: FLUKE-179/EDA2
- Country of Origin: US
- Currency: USD
- Dimensions: 185 MM Height X 90 MM Width X 43 MM Depth
- Display Type: Digital
- EU RoHS Indicator: U
- Frequency Rating: 100k Hz
- Gross Weight Per Pack: 2.2400 lb
- Gross Weight per Pack Metric: 1.02
- Gross Weight UOM Metric: kg
- Harmonization Tariff Schedule Code: 9030320000
- Height: 1.70 in
- Height [Metric]: 4.3180 cm
- Length: 7.28 in
- Length [Metric]: 18.4912 cm
- Model: 179/EDA2
- Resistance: 50 MOhm
- Safety Rating: CAT III 1000 V, CAT IV 600 V
- Standard: UL Listed, CSA Certified, TUV Listed And VDE Pending, EN 61010-1 to 1000 V CAT III, EN 61010-1 to 600 V CAT IV
- Temperature Rating: Operating: -10 To 50 DEG C, Storage: -30 To 60 DEG C °C
- Type: Combo Kit
- UNSPSC: 41113630
- UPC 11: 09596936279
- UPC 12: 095969362795
- Voltage Rating: 1,414k//1,000 VAC//VDC
- Width: 3.54 in
- Width [Metric]: 8.9916 cm
- Stock Status: NONSTOCK
- Brand: Fluke®
- Manufacturer: Fluke Corporation
- Brochure URL - 11095_BRO_3272127-6116-eng-c-w.pdf(Brochure URL)
- Brochure URL - BRO_3272127-6116-eng-c-w.pdf(Brochure URL)
- Catalog URL - IDW_DOCUMENT_2f1edfd2e686ce7b17ddd7170d25fd5e4bec9a6b1f4e27263ecb3a4c82e711ab.pdf(Catalog URL)
- http://www.fluke.com(Seller Home Page URL)
- http://www.fluke.com/(Seller Home Page URL)
- Install Instructions URL - ID-INS-FLUKE-179_EDA2.pdf(Install Instructions URL)
- Owners Manual URL - 11095_5DKXYH6EWI120FGA.jpg(Owners Manual URL)
- Owners Manual URL - F-IB179L_01a_h(Owners Manual URL)
- Spec Sheet URL - fluke-179-eda2-digital-multimeter-kit.html(Spec Sheet URL)
- Video - http://download.fluke.com/demo-PQ/170shock.html(Video)
- Warranty URL - 11095_WAR_FLUKE_Warranties_2014.pdf(Warranty URL)
- Features
| Industrial electricians work in tough environments, that's why we have kitted our Fluke 179 True RMS digital multimeter with industrial strength test lead probe kit in a compact lightweight soft case |
| Temperature rating 10 to 50 deg C |
| Diode test range 2.4 V +/- (1% + 2) |
| Battery type alkaline |
| Safety rating CAT IV 600 V and CAT III 1000 V |
| Digital 6000 count, update 4/sec, bar graph 33 segments, update 40/sec |
| Resistance range - 600 Ohm with accuracy of +/-(0.9% + 2), 6 kOhm, 60 kOhm, 600 kOhm, 6MOhm with accuracy of +/-(0.9% + 1), 50 MOhm with accuracy of +/-(1.5% + 3) |
| Capacitance range 1000 nF, 10 uF, 100 uF with accuracy of +/-(1.2% + 2), 9999 uF with accuracy of +/-10% typical |
| Frequency range- 99.99Hz, 999.9 Hz, 9.999 kHz, 99.99 kHz with accuracy of (0.1% + 1) |
| 200 hr typical alkaline |
| Resistance range- 600 Ohm with accuracy of +/-(0.9% + 2), 6 kOhm, 60 kOhm, 600 kOhm, 6MOhm with accuracy of +/-(0.9% + 1), 50 MOhm with accuracy of +/-(1.5% + 3) |
| Capacitance range 1000 nF, 10 uF, 100 uF with accuracy of +/-(1.2 % + 2), 9999 uF with accuracy of +/-10 % typical |
| Frequency range- 99.99Hz, 999.9 Hz, 9.999 kHz, 99.99 kHz with accuracy of (0.1 % + 1) |
| 200 hrs typical Alkaline |
