Sandvik Coromant 5758656 CoroMill® 327 Thread Milling Head, 327R09-18 100VM-TH 1025, 327..VM-TH Insert, Carbide, 1025, 327R09-18 100VM-TH 1025
327 Milling Inserts
1231300
MFG #: 5758656
Sandvik Coromant
87.89000
/ ea
- Alternate Catalog Number: 327R09-18 100VM-TH 1025
- ANSI Code: 327R09-18 100VM-TH 1025
- Catalog Number: 5758656
- Corner Radius: Carbide
- Country of Origin: SE
- Finish: PVD Coated
- Gross Weight Per Pack: 0.0100 lb
- Hand of Insert: Right
- Hole Diameter: 5.85 mm
- Included Angle: 60
- ISO Code: 327R09-18 100VM-TH 1025
- Item Group: 350
- Lead Angle: 3
- Length: 0.2303 in
- Pitch: 1
- Series: CoroMill® 327
- Thickness: 327R09-18 100VM-TH 1025
- Thread Standard: VM
- Thread Type: Internal
- Threads Per Inch: 12 to 24
- Type: Straight
- UPC 11: 69826244997
- Width: PVD Coated
- Stock Status: NONSTOCK
- Brand: Sandvik Coromant
- Manufacturer: Sandvik Coromant
- Chipbreaker: Straight
- Cutting Direction: Right Hand
- Inscribed Circle: 5.85 mm
- Insert Size: 327R09-18 100VM-TH 1025
- Insert Style: 327..VM-TH
- Manufacturer's Grade: 1025
- Material: Carbide
- Material Grade: K/M/N/P/S
- Rake: 1.5 deg Axial/5 deg Radial
- Shape: CoroMill® 327
- Features
| CoroMill® 327 adaptive interface |
| 1.2 mm maximum cutting depth |
| 10.62 mm Dia core at face |
| 0.12 mm spot chamfer |
| Without coolant entry |
| 17.7 mm Dia cutting |
| EFW feed direction |
| 0 deg neutral helix flute |
| 1.37 mm H thread |
| 0.12 mm H thread difference |
| 5.85 mm L functional |
| 5 mm L usable |
| 5.85 mm maximum overhang |
| 30 deg left hand and right hand profile |
| 60 deg included profile |
| VP60 thread form |
| 12 - 24 TPI |
| 1 - 2 mm pitch |
| 3 effective cutting edge |
| No coolant exit |
