nVent HOFFMAN C8C20 C5 Series Consolet Enclosure, 8 in L x 20 in W x 7.09 in D, NEMA 12/13/IP65 NEMA Rating, Steel
Console & Consolet Enclosures
25618
MFG #: C8C20
nVent HOFFMAN
357.88000
/ ea
- Application: Controls and Drives
- ARRA Compliant: C
- Buy American Compliant: C
- Catalog Number: C8C20
- Color: Gray
- Country of Origin: MX
- Currency: USD
- EU RoHS Indicator: NEW
- Finish: Powder Coat
- Gross Volume Per Pack: 1.08
- Gross Volume UOM: FC
- Gross Weight Per Pack: 15.0000 lb
- Gross Weight per Pack Metric: 6.80
- Gross Weight UOM Metric: kg
- Harmonization Tariff Schedule Code: 7326908688
- Height [Metric]: 21.5900 cm
- Item Group: C5
- Length [Metric]: 61.7220 cm
- Returnable: Y
- Size: 8.00x20.00x7.09 in
- Standard: UL 508A Listed, Type 12, 13, File No. E61997, cUL Listed per CSA C22.2 No. 94, Type 12, 13, File No. E61997, NEMA/EEMAC Type 12, 13 , CSA File Number 42186: Type 12, IEC 60529, IP65,
- Standards: UL 508A Listed, Type 12, 13, File No. E61997, cUL Listed per CSA C22.2 No. 94, Type 12, 13, File No. E61997, NEMA/EEMAC Type 12, 13 , CSA File Number 42186: Type 12, IEC 60529, IP65,, RoHS Complaint
- Type: HMI Enclosure Systems
- UNSPSC: 39121323
- UPC 11: 78351059510
- UPC 12: 78351059510
- Width [Metric]: 22.8600 cm
- Stock Status: NONSTOCK
- Brand: nVent HOFFMAN
- Manufacturer: HOFFMAN ENCLOSURES
- Depth: 7.09
- Height: 8.5000 in
- Length: 9.0000 in
- Material: Mild Steel
- Width: 24.3000 in
nVent HOFFMAN Consolet Enclosure, Series: C5 Series, 8 in Length, 20 in Width, 7.09 in Depth, NEMA 12/13/IP65, Continuous Hinged/Sloped Cover, Surface Mount, Steel, Polyester Powder Painted, Gray
- http://www.hoffmanonline.com(Seller Home Page URL)
- Install Instructions 1 URL - 11015_9KDB1L2EVXUOW584.pdf(Install Instructions 1 URL)
- Spec Sheet URL - Spec-00356.pdf(Spec Sheet URL)
- Install Instructions 1 URL - stream_document.aspx?rRID=19277&pRID=6826(Install Instructions 1 URL)
- Install Instructions URL - stream_document.aspx?rRID=19277&pRID=6826(Install Instructions URL)
- Tech Drawing URL - IDW_DOCUMENT_1518580516108.x-zip-compressed(Tech Drawing URL)
- Warranty URL - terms-of-sale(Warranty URL)
- Applications
- Features
| Controls and Drives |
| 14 gauge steel , Seams continuously welded and ground smooth; no holes or knockouts, Captivated cover screws thread into sealed wells, Bonding provision on cover, Oil-resistant gasket and adhesive, Control panel attached with continuous hinge along bottom edge |
| 14 ga steel body |
| Seams continuously welded and ground smooth, no holes or knockouts |
| Captivated cover screws thread into sealed wells |
| Bonding provision on cover |
| Oil-resistant gasket and adhesive |
| Control panel attached with continuous hinge along bottom edge |
