EGS 7125GSR 1-1/4 IN RT EMT CONN GR
Liquidtight Conduit Connectors
883692
MFG #: 7125GSR
Appleton™
14.39000
/ ea
- Application: To ground and secure EMT Raceways to boxes and enclosures in wet locations
- ARRA Compliant: N
- Buy American Compliant: N
- Catalog Number: 7125GSR
- Color: Metallic Body/Green Nut
- Connection: Male NPS Thread
- Country of Origin: IN
- Currency: USD
- Dimensions: 2.07 in Dia x 2 in L
- Environmental Conditions: Raintight
- EU RoHS Indicator: U
- Gross Weight Per Pack: 0.3700 lb
- Gross Weight per Pack Metric: 0.18
- Gross Weight UOM Metric: kg
- Height: 0.76 in
- Height [Metric]: 19.3040 mm
- Insulation: None
- Length: 6.90 in
- Length [Metric]: 17.5260 cm
- NEMA Rating: FB-1
- Series: 7000GSR
- Size: 1.25 IN in
- Standard: UL Standard: 514B; UL Listed: E14815, E14895; CSA Standard: C22.2 No. 18.3, cUL Listed: E14815; CSA Certified: 028507; NEMA: FB-1
- Standards: UL 514B File No. E14815/E14895CSA C22.2 No. 18.3, 028507cUL E14815NEMA FB-1
- Sub Brand: ETP
- Type: EMT Non-Insulated
- UNSPSC: 39121434
- UPC 11: 68785587663
- UPC 12: 68785587663
- Width: 4.40 in
- Width [Metric]: 11.1760 cm
- Stock Status: NORMALLY STOCKED
- Brand: Appleton™
- Manufacturer: Appleton
- Finish: Zinc Electroplated
- Material: Steel
- Trade Size: 1-1/4 in
- Applications
- Features
| To ground and secure EMT Raceways to boxes and enclosures in wet locations |
| UL Listed Raintight, No disassembly required, Concretetight |
| Zinc electroplated steel body and nut, silicone rubber internal sealing ring, EPDM rubber knockout sealing ring |
| InspectoRidge™ external visual inspection aid |
| No disassembly required |
| Threaded male NPS hub |
