Square D™ CHU361AWK Heavy Duty Non-Fusible Single Throw Disconnect Switch With Viewing Window, 600 VAC/VDC, 30 A, 5 hp, TPST Contact, 3 Poles
Custom_Product_Images_Illustration
Square D™ CHU361AWK Heavy Duty Non-Fusible Single Throw Disconnect Switch With Viewing Window, 600 VAC/VDC, 30 A, 5 hp, TPST Contact, 3 Poles
SKUPDW~6398060
MFGR #CHU361AWK
Your Cost: $758.14/ea
List: Square D™ Disconnect Switch, Heavy Duty Non-Fusible Single Throw, Series, 600, Amperage Rating VAC/VDC, A 30, 5, Phase hp, Number of Poles, 3 Wires, Short Circuit Current Rating, kA 10, TPST, Actuator Type, Phenolic Insulation, Enclosure Type, Surface Mount, Terminal Type, Dimensions, Steel, Color, Galvannealed
Square D™ Disconnect Switch, Heavy Duty Non-Fusible Single Throw, Series, 600, Amperage Rating VAC/VDC, A 30, 5, Phase hp, Number of Poles, 3 Wires, Short Circuit Current Rating, kA 10, TPST, Actuator Type, Phenolic Insulation, Enclosure Type, Surface Mount, Terminal Type, Dimensions, Steel, Color, Galvannealed
Alternate Catalog Number CHU361AWK Application Commercial and Industrial Applications ARRA Compliant N Buy American Compliant N Catalog Number CHU361AWK Connection LUGS Country of Origin US Currency USD EU RoHS Indicator Y Gross Volume Per Pack 750.75 Gross Volume per Pack Metric 12302.54 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 10.0800 lb Gross Weight per Pack Metric 4.57 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536509045 Height 13.9700 in Height [Metric] 13.9700 cm Item Group 00153 Length 44.4500 in Length [Metric] 44.4500 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=363317&lang=en-us Mounting Surface Number Of Poles 3 Returnable Y Type Non-fusible disconnect;Single Throw Safety Switch UNSPSC 39122218 UPC 11 78590199452 UPC 12 785901994527 Width 19.8120 in Width [Metric] 19.8120 cm Wire Type AWG 12...AWG 6 aluminium;AWG 14...AWG 6 copper Brand Square D™ Manufacturer Schneider Electric Voltage Rating 600 VAC//VDC Commercial and Industrial Applications Visible blades for positive indication that switch is "Off" Quick-make/quick-break operating mechanism Lugs suitable for aluminum or copper conductors Multiple padlock provisions in the "Off" position Spring reinforced, plated copper fuse clips Red and black handle indicates the On (red) or Off (black) switch position Dual cover interlock Single throw action Without knockout
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | CHU361AWK |
| Application | Commercial and Industrial Applications |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | CHU361AWK |
| Connection | LUGS |
| Country of Origin | US |
| Currency | USD |
| EU RoHS Indicator | Y |
| Gross Volume Per Pack | 750.75 |
| Gross Volume per Pack Metric | 12302.54 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 10.0800 lb |
| Gross Weight per Pack Metric | 4.57 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536509045 |
| Height | 13.9700 in |
| Height [Metric] | 13.9700 cm |
| Item Group | 00153 |
| Length | 44.4500 in |
| Length [Metric] | 44.4500 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=363317&lang=en-us |
| Mounting | Surface |
| Number Of Poles | 3 |
| Returnable | Y |
| Type | Non-fusible disconnect;Single Throw Safety Switch |
| UNSPSC | 39122218 |
| UPC 11 | 78590199452 |
| UPC 12 | 785901994527 |
| Width | 19.8120 in |
| Width [Metric] | 19.8120 cm |
| Wire Type | AWG 12...AWG 6 aluminium;AWG 14...AWG 6 copper |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Voltage Rating | 600 VAC//VDC |
| Commercial and Industrial Applications |
| Visible blades for positive indication that switch is "Off" |
| Quick-make/quick-break operating mechanism |
| Lugs suitable for aluminum or copper conductors |
| Multiple padlock provisions in the "Off" position |
| Spring reinforced, plated copper fuse clips |
| Red and black handle indicates the On (red) or Off (black) switch position |
| Dual cover interlock |
| Single throw action |
| Without knockout |
