Advance ICF2S26M1BS35M SmartMate Electronic Compact Fluorescent Ballast, CFQ26W/G24Q Lamp, 26 W, 120 to 277 VAC, Programmed
Custom_Product_Images_Illustration
Advance ICF2S26M1BS35M SmartMate Electronic Compact Fluorescent Ballast, CFQ26W/G24Q Lamp, 26 W, 120 to 277 VAC, Programmed
SKU83993
MFGR #ICF2S26M1BS35M
Your Cost: $35.70/ea
List: Offering maximum versatility, the Advance family of SmartMate® electronic ballasts for 4-pin compact fluorescent lamps drive a broad range of quad and triple tube, circline, 2D and long twin tube lamps. Representing an innovative breakthrough in CFL ballast technology, SmartMate® ballasts energy-efficient design, compact and lightweight housing and user-friendly features make SmartMate® ballasts an ideal choice for fixture manufacturers, retrofitters and MRO replacement. SmartMate® ballasts are ideal in such applications as restaurants, reception areas, conference and meeting rooms, hotel and convention center ballrooms and houses of worship, as well as in place of incandescent down lighting systems.
Offering maximum versatility, the Advance family of SmartMate® electronic ballasts for 4-pin compact fluorescent lamps drive a broad range of quad and triple tube, circline, 2D and long twin tube lamps. Representing an innovative breakthrough in CFL ballast technology, SmartMate® ballasts energy-efficient design, compact and lightweight housing and user-friendly features make SmartMate® ballasts an ideal choice for fixture manufacturers, retrofitters and MRO replacement. SmartMate® ballasts are ideal in such applications as restaurants, reception areas, conference and meeting rooms, hotel and convention center ballrooms and houses of worship, as well as in place of incandescent down lighting systems.
Alternate Catalog Number ICF2S26M1BS35M Amperage Rating 0.19 to 0.43 A ARRA Compliant C Buy American Compliant C Catalog Number ICF2S26M1BS35M Country of Origin MX Currency USD Dimensions 4.6 in L x 2.4 in W x 0.98 in H Dimmable NON DIMMABLE W EU RoHS Indicator C Frequency Rating 50to60 Hz Gross Volume per Pack Metric 167.34 Gross Volume UOM Metric cm3 Gross Weight Per Pack 1.0000 lb Gross Weight per Pack Metric 0.25 Gross Weight UOM Metric kg Height 1.00 in Height [Metric] 2.5400 cm Lamp Base Type 4-Pin G24q Length 4.25 in Length [Metric] 10.8000 cm Material Metal Number Of Lamps 2 Power Factor 1.00 Standard CSA certificate;UL certificate;CEC Listing;RoHS Compliant Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL File No. E14927CSA File No. 007310 Sub Brand Centium/Smartmate Temperature Range 75 °C Total Harmonic Distortion 10% Type Electronic UNSPSC 39101901 UPC 11 78108710406 UPC 12 781087104064 Wattage 51 W Width 2.40 in Width [Metric] 6.1000 cm Stock Status NONSTOCK Brand Advance Manufacturer Signify Ballast Factor 1 PCT Lamp Type CFL Lamp Wattage 26 W Start Type Programmed Voltage Rating 120 to 277 VAC Certifications are UL, ISO, FCC IntelliVolt technology (120 to 277 VAC)
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | ICF2S26M1BS35M |
| Amperage Rating | 0.19 to 0.43 A |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | ICF2S26M1BS35M |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 4.6 in L x 2.4 in W x 0.98 in H |
| Dimmable | NON DIMMABLE W |
| EU RoHS Indicator | C |
| Frequency Rating | 50to60 Hz |
| Gross Volume per Pack Metric | 167.34 |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 1.0000 lb |
| Gross Weight per Pack Metric | 0.25 |
| Gross Weight UOM Metric | kg |
| Height | 1.00 in |
| Height [Metric] | 2.5400 cm |
| Lamp Base Type | 4-Pin G24q |
| Length | 4.25 in |
| Length [Metric] | 10.8000 cm |
| Material | Metal |
| Number Of Lamps | 2 |
| Power Factor | 1.00 |
| Standard | CSA certificate;UL certificate;CEC Listing;RoHS Compliant |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL File No. E14927CSA File No. 007310 |
| Sub Brand | Centium/Smartmate |
| Temperature Range | 75 °C |
| Total Harmonic Distortion | 10% |
| Type | Electronic |
| UNSPSC | 39101901 |
| UPC 11 | 78108710406 |
| UPC 12 | 781087104064 |
| Wattage | 51 W |
| Width | 2.40 in |
| Width [Metric] | 6.1000 cm |
| Stock Status | NONSTOCK |
| Brand | Advance |
| Manufacturer | Signify |
| Ballast Factor | 1 PCT |
| Lamp Type | CFL |
| Lamp Wattage | 26 W |
| Start Type | Programmed |
| Voltage Rating | 120 to 277 VAC |
| Certifications are UL, ISO, FCC |
| IntelliVolt technology (120 to 277 VAC) |
