Schneider Electric TeSys™ F LX1FH3802 Coil, 380/415 VAC, 40 to 400 Hz, For Use With LC1F265, LC1F330 Contactor
Custom_Product_Images_Illustration
Schneider Electric TeSys™ F LX1FH3802 Coil, 380/415 VAC, 40 to 400 Hz, For Use With LC1F265, LC1F330 Contactor
SKUPDW~6409194
MFGR #LX1FH3802
Your Cost: $203.70/ea
Schneider Electric TeSys™ F Coil, Series: LX1, 380/415 VAC, 40 to 400 Hz, For Use With: LC1F265, LC1F330 Contactor
Schneider Electric TeSys™ F Coil, Series: LX1, 380/415 VAC, 40 to 400 Hz, For Use With: LC1F265, LC1F330 Contactor
Alternate Catalog Number LX1FH3802 Application LC1F330-LC1F265,TESYS F LC1F CONTACTOR ARRA Compliant N Buy American Compliant N Catalog Number LX1FH3802 Coil Power Rating 10-10 VA 40...400 HZ 0.3 20 A°C) Coil Voltage 380 to 415@40 to 400Hz VAC Country of Origin CZ Currency USD EU RoHS Indicator Y Gross Volume Per Pack 105.12 Gross Volume per Pack Metric 1722.60 Gross Weight Per Pack 1.8700 lb Gross Weight per Pack Metric 0.85 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8504508000 Height 7.23 in Height [Metric] 18.5400 cm Item Group 22341 Length 3.56 in Length [Metric] 9.1400 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=641310&lang=en-us Operating Temperature -5-55 A°C Returnable N Sub Brand TESYS,TESYS F Type CONTACTOR COIL UNSPSC 39121529 UPC 11 785901873198 UPC 12 785901873198 Warranty Description Contractual Warranty:18 months Width 3.96 in Width [Metric] 10.1600 cm Brand Square D™ Manufacturer Schneider Electric LC1F330-LC1F265,TESYS F LC1F CONTACTOR WITHOUT BUILT-IN SUPPRESSOR MODULE 217 Ohm at 20 deg C, 4631 Ohm holding at 20 deg C average resistance 100 to 170 ms closing, 40 to 65 ms opening operating time 10000000 cycles mechanical durability 2400 cycles/hr at <=131 deg F operating time Without built-in suppressor module coil technology 0.35 to 0.55 Uc at 55 deg C drop out 40 to 400 Hz, 0.85 to 1.1 Uc at 55 deg C operational 40 to 400 Hz control circuit voltage limits 650 VA at 20 deg C (cos f 0.9) 40 to 400 Hz inrush power 10 VA at 20 deg C (cos f 0.3) 40 to 400 Hz hold-in power consumption 8 W at 40 to 400 Hz heat dissipation AC control circuit AC control circuit
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | LX1FH3802 |
| Application | LC1F330-LC1F265,TESYS F LC1F CONTACTOR |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | LX1FH3802 |
| Coil Power Rating | 10-10 VA 40...400 HZ 0.3 20 A°C) |
| Coil Voltage | 380 to 415@40 to 400Hz VAC |
| Country of Origin | CZ |
| Currency | USD |
| EU RoHS Indicator | Y |
| Gross Volume Per Pack | 105.12 |
| Gross Volume per Pack Metric | 1722.60 |
| Gross Weight Per Pack | 1.8700 lb |
| Gross Weight per Pack Metric | 0.85 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8504508000 |
| Height | 7.23 in |
| Height [Metric] | 18.5400 cm |
| Item Group | 22341 |
| Length | 3.56 in |
| Length [Metric] | 9.1400 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=641310&lang=en-us |
| Operating Temperature | -5-55 A°C |
| Returnable | N |
| Sub Brand | TESYS,TESYS F |
| Type | CONTACTOR COIL |
| UNSPSC | 39121529 |
| UPC 11 | 785901873198 |
| UPC 12 | 785901873198 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 3.96 in |
| Width [Metric] | 10.1600 cm |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| LC1F330-LC1F265,TESYS F LC1F CONTACTOR |
| WITHOUT BUILT-IN SUPPRESSOR MODULE |
| 217 Ohm at 20 deg C, 4631 Ohm holding at 20 deg C average resistance |
| 100 to 170 ms closing, 40 to 65 ms opening operating time |
| 10000000 cycles mechanical durability |
| 2400 cycles/hr at <=131 deg F operating time |
| Without built-in suppressor module coil technology |
| 0.35 to 0.55 Uc at 55 deg C drop out 40 to 400 Hz, 0.85 to 1.1 Uc at 55 deg C operational 40 to 400 Hz control circuit voltage limits |
| 650 VA at 20 deg C (cos f 0.9) 40 to 400 Hz inrush power |
| 10 VA at 20 deg C (cos f 0.3) 40 to 400 Hz hold-in power consumption |
| 8 W at 40 to 400 Hz heat dissipation |
| AC control circuit |
| AC control circuit |
