Siemens
Sentron™ 5SJ4302-7HG42 Miniature Circuit Breaker, 480 VAC/125 VDC, 2 A, 14 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Siemens
Sentron™ 5SJ4302-7HG42 Miniature Circuit Breaker, 480 VAC/125 VDC, 2 A, 14 kA Interrupt, 3 Poles, Thermal Magnetic Trip
SKU604422
MFGR #5SJ4302-7HG42
Your Cost: $197.49/ea
List: SIEMENS 5SJ4302-7HG42 MCB UL489 3-P 480Y/277VAC 2A C TYPE NSJ
SIEMENS 5SJ4302-7HG42 MCB UL489 3-P 480Y/277VAC 2A C TYPE NSJ
Actuator Type Handle Alternate Catalog Number 5SJ4302-7HG42 Application BRANCH CIRCUIT PROTECTORS ARRA Compliant C Buy American Compliant C Catalog Number 5SJ4302-7HG42 Connection Identical wire screw connections on line and load side. Connection Type Line/Load/Screw Country of Origin DE Currency USD Dimensions 121 mm H x 54 mm W x 70 mm D Enclosure Type IP20 EU RoHS Indicator C Frequency Rating 50 Hz Gross Volume Per Pack 229.11 Gross Volume UOM in Gross Weight Per Pack 1.1100 lb Gross Weight per Pack Metric 0.50 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200040 Height 3.4500 in Height [Metric] 8.7630 cm Length 1.7000 in Length [Metric] 4.3180 cm Material N/A Mounting Type DIN Rail Number Of Poles 3 Phase 3 Returnable Y Standard UL 489, CSA 22.2 NO. 5-02, HACR, IEC/EN 60 898, IEC/EN 60 947-2 Standards ARRA CompliantBuy American Act CompliantRoHS CompliantCSA 22.2 No. 5-02CE MarkedcULus ListedIEC/EN 60898IEC/EN 60947-2HACR RatedUL 489 File No. E243414 Sub Brand SENTRON Temperature Rating -25 to 55 °C Type Type NSJ UNSPSC 39121601 UPC 11 75455496022 UPC 12 754554960227 Width 5.0500 in Width [Metric] 12.8270 cm Wire Size 14 to 4 AWG Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 2 A Interrupt Rating 14 kA Trip Type Thermal Magnetic Voltage Rating 240 VAC BRANCH CIRCUIT PROTECTORS 3-POLE 40 deg C calibration base (industrial applications) 30 deg C calibration base Can be used for field wiring applications 14 to 4 AWG copper only Suitable for reverse feed applications C-trip is designed for general device protection in control circuits and all other miniature circuit breaker systems. Magnetic trip point is 5 to 10 times the MCB rating 0.75 to 35 mm2 solid and stranded conductors Visible indicator for on and off/trip Touch protection to EN50274 Identical wire screw connections on line and load sides Smaller size than traditional MCCBs 35 mm DIN standard mounting rail Short circuit rating: 14 kA 277/480 VAC/125 VDC
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator Type | Handle |
| Alternate Catalog Number | 5SJ4302-7HG42 |
| Application | BRANCH CIRCUIT PROTECTORS |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | 5SJ4302-7HG42 |
| Connection | Identical wire screw connections on line and load side. |
| Connection Type | Line/Load/Screw |
| Country of Origin | DE |
| Currency | USD |
| Dimensions | 121 mm H x 54 mm W x 70 mm D |
| Enclosure Type | IP20 |
| EU RoHS Indicator | C |
| Frequency Rating | 50 Hz |
| Gross Volume Per Pack | 229.11 |
| Gross Volume UOM | in |
| Gross Weight Per Pack | 1.1100 lb |
| Gross Weight per Pack Metric | 0.50 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 3.4500 in |
| Height [Metric] | 8.7630 cm |
| Length | 1.7000 in |
| Length [Metric] | 4.3180 cm |
| Material | N/A |
| Mounting Type | DIN Rail |
| Number Of Poles | 3 |
| Phase | 3 |
| Returnable | Y |
| Standard | UL 489, CSA 22.2 NO. 5-02, HACR, IEC/EN 60 898, IEC/EN 60 947-2 |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantCSA 22.2 No. 5-02CE MarkedcULus ListedIEC/EN 60898IEC/EN 60947-2HACR RatedUL 489 File No. E243414 |
| Sub Brand | SENTRON |
| Temperature Rating | -25 to 55 °C |
| Type | Type NSJ |
| UNSPSC | 39121601 |
| UPC 11 | 75455496022 |
| UPC 12 | 754554960227 |
| Width | 5.0500 in |
| Width [Metric] | 12.8270 cm |
| Wire Size | 14 to 4 AWG |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 2 A |
| Interrupt Rating | 14 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 240 VAC |
| BRANCH CIRCUIT PROTECTORS |
| 3-POLE |
| 40 deg C calibration base (industrial applications) |
| 30 deg C calibration base |
| Can be used for field wiring applications 14 to 4 AWG copper only |
| Suitable for reverse feed applications |
| C-trip is designed for general device protection in control circuits and all other miniature circuit breaker systems. Magnetic trip point is 5 to 10 times the MCB rating |
| 0.75 to 35 mm2 solid and stranded conductors |
| Visible indicator for on and off/trip |
| Touch protection to EN50274 |
| Identical wire screw connections on line and load sides |
| Smaller size than traditional MCCBs |
| 35 mm DIN standard mounting rail |
| Short circuit rating: 14 kA |
| 277/480 VAC/125 VDC |
